Screen Ratio

7″high digital new panel ,16:9image

Back Light

LED,400cd/㎡

Resolution

800xRGBx480

function

Light sensor automatic adjustment

Compatible system

NTSC & PAL (automatically)

OSD control

Color, Brightness, Contrast, Volume, Language

(English, Deutsch, French, Spanish, Portugal, Italian, Dutch, Simplify Chinese)

View angel

Hor. L(70) R(70)   Ver. UP(50) DOWN(70)

Power requirement

9-45V DC

Power consumption

7W

Storage temperature

-30〜80℃

Working temperature

-20℃ to 70℃

Size

210*134*26(76)mm

Exterior color

Black rubber oiling,Detachable sunshade&Metal,U type bracket

AV Inputs

4 way video input, 1 way audio input（quad images,2/3/4 images optional）

Number of Trigger

and display

4 triggers

Monitor And Camera

Connector

RCA/ 4pin connector (Optional)

Accessories

Remote controller, Power supply cable , User manual, Bracket
